Aux LED 9500 Lu (pair) - Squadron Pro + Racer
Utilising 4 powerful Cree LEDs combined with its unique styling and lightweight, set this kit apart from any other. If you’re looking for the ultimate addition to your Adventure Bike, look no further.
Specifications (per light):
Lumens: 4,600 Utilizing 4 Cree LEDs each (so 9200 Lumens for a pair)
Wattage/Amps: 40W / 2.9A
Dimensions: 3.07" x 2.77" x 3.07"
Weight: 12 ounces
LED Life Expectancy: 49,930 Hours
Front Lens: Hard Coated Polycarbonate
Housing: Powder Coated Cast Aluminum
Bezel: Billet Machined Aluminum
Hardware & Bracket Material: Stainless Steel
Exceeds MIL-STD810G (Mil-Spec Testing)
Built-In Over voltage Protection
IP69K (Waterproof, Submersible to 9ft)
IK10 Compliant (Mechanical Impact Testing)
Baja Designs Features:
uService® – Replaceable Lenses And Optics
Clear View® – All The Light, Right Where You Need It.
Moisture Block™ – Waterproof, Rain Proof, Submersible
Copper Drive® – Only LED Driven At 100%
5000K Daylight – Less Driver Fatigue, Natural Color
New BTM :- Battery management Tech
Squadron Pro data Sheet
Contains:
(2) LED Lights
LED Holding Brackets (Not Engine bar clamps)
Along with the lights kit Baja Designs provides a Complimentary Basic wiring harness, basic switch but with no relay or Posi-tabs.
If you would like to upgrade to better motorcycle ready kit here are your options
A Baja Designs Adventure Wiring harness that includes a premium quality switch and relay please purchase these add ons. Wiring and Switch
Optionally you can request us (in your order notes) or a dealer to add the relay of posi-tabs to the “Complimentary Basic wiring harness” and they will update the wiring towards the cause.
Pattern:
Driving/Combo: Maximum trail coverage in a single light. The Driving/Combo pattern is equipped with both Wide Driving (42°) and the spot (9°) optics to provide you with a smooth blend of light for both near field applications and distance
Spot: A longer and narrower 9° beam focus for illumination further down the trail or road. The Spot pattern is designed to be used in conjunction with additional Wide Driving and/or Driving/Combo beam lights
